Heat Resistant Tensile PTFE Coated Fiberglass Mesh Glass Fiber Fabric

Heat Resistant Tensile PTFE Coated Fiberglass Mesh Glass Fiber Fabric

Brand: WELLFLON
Materials: PTFE (Teflon), Fiberglass Fabric
Yarn Type: Filament Yarn/Texturized Yarn
Weave Type: Plain
Width Range: 1000~4000mm
Features: Non-stick, High-Temp Resistant
Temperature Resistance: -70°C ~ +280°C
Color: Brow/Black/White /Custom Color
Certification: FDA/LFGB/SGS/RoHS/UL
Quality Assurance: 1 Year

Heat Resistant Tensile PTFE Coated Fiberglass Mesh Glass Fiber Fabric, also known as Teflon high temperature fabric, high temperature welding cloth, PTFE high temperature cloth,etc., is made of high-quality imported glass fiber fabric as the base material. Through unique processing technology, it is repeatedly fully impregnated and coated with high-quality PTFE (Teflon) resin to produce Teflon high temperature coated fabric of various thicknesses.

The Main Features of Heat Resistant Tensile PTFE Coated Fiberglass Mesh Glass Fiber Fabric of various thicknesses:

1. Used for low temperature -196 degrees and high temperature 300 degrees, it has weather resistance and anti-aging;

2. Non-adhesive: not easy to adhere to most substances, easy to clean;

3. Chemical corrosion resistance, strong acid, strong alkali, aqua regia and various organic solvents;

4. Low friction coefficient (0.05-1), a good choice for oil-free self-lubrication;

5. It has high insulation performance (small dielectric constant: 2.6, tangent below 0.0025), UV protection, anti-static

6. Good dimensional stability (elongation coefficient less than 0.5%) and high strength. It has good mechanical properties.

Application Range of Heat Resistant Tensile PTFE Coated Fiberglass Mesh Glass Fiber Fabric of various thicknesses :

1. Anti-stick lining, gasket, cover cloth and conveyor belt; according to different thickness, it can be used for conveyor belts, adhesive belts, sealing belts, etc. of various drying machines;

2. Welding cloth for plastic products welding and welding; plastic sheets, films, heat-sealed sheet lining tapes;

3. Electrical high insulation: electrical insulation tape base, spacers, gaskets, lining rings;

4. Microwave gaskets, oven sheets, food drying.

5. Solar laminator high temperature cloth (generally with a thickness of 0.25mm, 0.30mm, 0.35mm and a width of 2.2m)

The Common Specifications of Heat Resistant Tensile PTFE Coated Fiberglass Mesh Glass Fiber Fabric of various thicknesses:

(Customized 0.05mm-1.5mm arbitrary thickness)

Main Specifications of Heat Resistant Tensile PTFE Coated Fiberglass Mesh Glass Fiber Fabric of various thicknesses:

Item	Color	Thickness	Max Width	Weight	Tensile Strength	Temperature
CWF-T0158	Brown/Black/White	0.08mm	1250mm	158±5g/m2	500/480N/50mm	-70~280 ℃
CWF-T0160	Brown/Black/White	0.08mm	1250mm	160±5 g/m 2	620/460N/50mm	-70~280 ℃
CWF-T0180	Brown/Black/White	0.08mm	1250mm	180±5 g/m 2	930/720N/50mm	-70~280 ℃
CWF-T0260	Brown/Black/White	0.13mm	1250mm	260±5 g/m 2	100/1000N/50mm	-70~280 ℃
CWF-T0275	Brown/Black/White	0.13mm	1250mm	275±5 g/m 2	1000/960N/50mm	-70~280 ℃
CWF-T0290	Brown/Black/White	0.13mm	1250mm	290±5 g/m 2	910/880N/50mm	-70~280 ℃
CWF-T0395	Brown/Black/White	0.18mm	1250mm	395±5g/m 2	1600/1600N/50mm	-70~280 ℃
CWF-T0415	Brown/Black/White	0.18mm	1250mm	415±5 g/m 2	1500/1500N/50mm	-70~280 ℃
CWF-T0490	Brown/Black/White	0.25mm	2800mm	490±5 g/m 2	2100/1800N/50mm	-70~280 ℃
CWF-T0510	Brown/Black/White	0.25mm	2800mm	510±5 g/m 2	2800/2700N/50mm	-70~280 ℃
CWF-T0660	Brown/Black/White	0.35mm	3200mm	660±5 g/m 2	2700/2600N/50mm	-70~280 ℃
CWF-T0680	Brown/Black/White	0.35mm	3200mm	680±5 g/m 2	2100/2200N/50mm	-70~280 ℃
CWF-T0780	Brown/Black/White	0.40mm	3500mm	780±5 g/m 2	2900/3100N/50mm	-70~280 ℃
CWF-T0820	Brown/Black/White	0.40mm	3500mm	820±5 g/m 2	3000/2900N/50mm	-70~280 ℃
CWF-T1150	Brown/Black/White	0.65mm	4000mm	1150±5 g/m 2	4200/4000N/50mm	-70~280 ℃
CWF-T1550	Brown/Black/White	0.90mm	4000mm	1550±5 g/m 2	6300/5800N/50mm	-70~280 ℃
CWF-T1650	Brown/Black/White	0.90mm	4000mm	1650±5 g/m 2	6150/5300N/50mm	-70~280 ℃
