Brand: WELLFLON
Materials: PTFE (Teflon), Fiberglass Fabric
Yarn Type: Filament Yarn/Texturized Yarn
Width Range: 1000~4000mm
Features: Non-stick, High-Temp Resistant
Temp. Resistance: -70°C to +280°C
Color: Brow/Black/White /Custom Color
Certification: FDA/LFGB/SGS/RoHS/UL
Teflon high temperature cloth, also known as Teflon high temperature cloth, high temperature welding cloth, PTFE high temperature cloth, etc., is made of high-quality imported glass fiber cloth as the base material. Through unique processing technology, it is repeatedly fully impregnated and coated with high-quality Teflon resin to produce Teflon high temperature coated cloth of various thicknesses.
The Main Features of PTFE (Teflon) glass fiber high temperature coated cloth:
1. Used for low temperature -196 degrees and high temperature 300 degrees, it has weather resistance and anti-aging;
2. Non-adhesive: not easy to adhere to most substances, easy to clean;
3. Chemical corrosion resistance, strong acid, strong alkali, aqua regia and various organic solvents;
4. Low friction coefficient (0.05-1), a good choice for oil-free self-lubrication;
5. It has high insulation performance (small dielectric constant: 2.6, tangent below 0.0025), UV protection, anti-static
6. Good dimensional stability (elongation coefficient less than 0.5%) and high strength. It has good mechanical properties.
Application Range of PTFE (Teflon) glass fiber high temperature coating cloth:
1. Anti-stick lining, gasket, cover cloth and conveyor belt; according to different thickness, it can be used for conveyor belts, adhesive belts, sealing belts, etc. of various drying machines;
2. Welding cloth for plastic products welding and welding; plastic sheets, films, heat-sealed sheet lining tapes;
3. Electrical high insulation: electrical insulation tape base, spacers, gaskets, lining rings;
4. Microwave gaskets, oven sheets, food drying.
5. Solar laminator high temperature cloth (generally with a thickness of 0.25mm, 0.30mm, 0.35mm and a width of 2.2m)
The common specifications of PTFE (Teflon) glass fiber high temperature coating cloth are as follows:
(Customized 0.05mm-1.5mm arbitrary thickness)
|
Color |
Thickness (mm) |
Weight of Fiberglass(g/m2)±3% |
Total Weight (g/m2) ±5% |
Tear Strength (N/5cm) ±5% |
Temperature Resistance |
|
Warp |
Weft |
||||||
CWF-0070 |
black/white/brown |
0.065 |
48 |
70 |
500 |
460 |
-70 ~+280℃ |
CWF-0150 |
black/white/brown |
0.07 |
48 | 150 | 650 | 550 |
-70 ~+280℃ |
CWF-0165 |
black/white/brown |
0.08 | 48 | 165 | 700 | 600 |
-70 ~+280℃ |
CWF-0130 |
black/white/brown |
0.095 |
105 | 130 | 820 | 800 |
-70 ~+280℃ |
CWF-0220 |
black/white/brown |
0.105 |
105 | 220 | 900 | 750 |
-70 ~+280℃ |
CWF-0230 |
black/white/brown |
0.115 |
105 | 230 | 1150 | 1000 |
-70 ~+280℃ |
CWF-0250 |
black/white/brown |
0.125 |
105 | 250 | 1200 | 1100 |
-70 ~+280℃ |
CWF-0300 |
black/white/brown |
0.14 |
105 | 300 | 1350 | 1250 |
-70 ~+280℃ |
CWF-0350 |
black/white/brown |
0.17 |
165 | 350 | 1750 | 1550 |
-70 ~+280℃ |
CWF-0360 |
black/white/brown |
0.18 |
165 | 360 | 1800 | 1650 |
-70 ~+280℃ |
CWF-0275 |
black/white/brown |
0.2 |
205 | 275 | 2000 | 1800 |
-70 ~+280℃ |
CWF-0440 |
black/white/brown |
0.22 |
205 | 440 | 2400 | 1650 |
-70 ~+280℃ |
CWF-0490 |
black/white/brown |
0.23 |
205 | 490 | 2200 | 1750 |
-70 ~+280℃ |
CWF-0500 |
black/white/brown |
0.24 |
205 | 500 | 2200 | 1850 |
-70 ~+280℃ |
CWF-0500 |
black/white/brown |
0.25 |
205 | 500 | 2500 | 2000 |
-70 ~+280℃ |
CWF-0620 |
black/white/brown |
0.28 |
293 | 620 | 2500 | 1800 |
-70 ~+280℃ |
CWF-0385 |
black/white/brown |
0.31 |
283 | 385 | 1900 | 1400 |
-70 ~+280℃ |
CWF-0620 |
black/white/brown |
0.32 |
255 | 620 | 3000 | 2100 |
-70 ~+280℃ |
CWF-0690 |
black/white/brown |
0.35 |
333 | 690 | 3200 | 2200 |
-70 ~+280℃ |
CWF-0770 |
black/white/brown |
0.39 |
333 | 770 | 3200 | 2100 |
-70 ~+280℃ |
CWF-0540 |
black/white/brown |
0.43 |
405 | 540 | 3500 | 2400 |
-70 ~+280℃ |
CWF-1000 |
black/white/brown |
0.53 |
538 | 1000 | 4200 | 3500 |
-70 ~+280℃ |
CWF-1180 |
black/white/brown |
0.63 | 578 | 1180 | 4500 | 3800 |
-70 ~+280℃ |
CWF-1550 |
black/white/brown |
0.78 | 768 | 1550 | 5500 | 4000 |
-70 ~+280℃ |
CWF-1600 |
black/white/brown |
0.9 | 865 | 1600 | 6500 | 5500 |
-70 ~+280℃ |
CWF-1250 |
black/white/brown |
0.98 | 852 | 1250 | 6000 | 5000 | -70 ~+280℃ |
